Footwear Safety Categories Guide
Safety Categories and definitions.
PB
- Toe
protection tested to 100 Joules
SB
- Toe
protection tested to 200 Joules impact and 15,000 Newtons compression
S1
- Toe
protection tested to 200 Joules Impact and 15,000 Newtons compression
- Antistatic
- Energy absorbing heel
S2
- Toe protection tested to 200 Joules
impact and 15,000 Newtons compression
- Antistatic and Energy absorbing heel
- Water resistant upper
S3
- Toe
protection tested to 200 Joules impact and 15,000 Newtons compression
- Antistatic
- Energy absorbing heel
- Water resistant upper
- Penetration resistant sole
S4
- Toe
protection tested to 200 Joules impact and 15,000 Newtons compression
- Antistatic and Energy
absorbing heel
- Waterproof polymer upper
S5
- Toe
protection tested to 200 Joules impact and 15,000 Newtons compression
- Antistatic
- Energy absorbing heel
- Waterproof polymer upper
- Penetration resistant sole
HRO
- Resistance to
high heat 300ºc
P
- Penetration
resistance 1100 Newtons
WR
- Water
resistant
SRA
- Tested on
ceramic wetted tile contamination with a diluted soap solution.
SRB
- Tested on
smooth steel contamination with glycerol.
SRC
- Passes SRA
& SRB tests
Sole Materials
PU Polyurethane, is a synthetic material:
Flexible and lightweight
Resistant to 130°C heat, oil
and low concentration acids/alkalis and solvents
N Nitrile
rubber, is a synthetic rubber copolymer of acrylonitrile and butadiene:
More resistant than natural
rubber to oils and acids, not as strong or flexibility
Better puncture-resistance
than natural rubber
R Rubber, (vulcanised caoutchouc) produced
from the latex sap:
Resistant to 200°C (300 if HRO)
heat, oil, low concentration acids/alkalis and solvents
VR Vulcanised
Rubber, Vulcanization chemically combines the rubber and sulfur.
PVC PVC , is a water resistant polymer:
Resistant to minerals, oil and fats. Resistant to 90°C heat, oil and low concentrations acids/alkalis and solvents.
PVN PVC/Nitrile, PVC combined with Nitrile to produce a harder wearing sole:
Resistant to 100°C
heat, oil and low concentration acids/alkalis and solvents
PH Phylon, compressed ethylene vinyl acetate, expanded using heat and cooled in a mould.
Light and flexible with good cushioning.
RPH Rubber/Phylon combined, usually with rubber in the midsole for flexible and resilient cushioning.
Uppers
Leather:
A processed natural product. Has durability, elasticity and ability to keep its shape. Holds heat and resists moisture.
Nubuck
(not to be confused with suede) Nubuck is a top-grain rawhide leather with good strength, thickness and resistance to wear. Nubuck is fine leather that has been sanded on the grain side. Fine calfskin and cowhides are normally used in the manufacture Nubuck remains water-resistant for a long time, is extremely supportive.
